VOLARE
Linear Pendant Lights
Volare linear pendant seemingly floats in space with a beautiful translucent acrylic diffuser. The translucent diffuser gently curves around a thin LED lightbar. Hidden hardware and minimalist shape echo traditional Scandinavian designs bringing a more stylized option into the linear pendant lighting market.
- Offered in three sizes ranging from 4' - 7'
- High or low lumen output; ambient illumination in up and down directions
- Suspended via black, white, or grey cloth braided power cord.
- Translucent acrylic shade gently curves over a thin lightbar
- Light bar is suspended under the acrylic with hidden supports and appears to float underneath the illuminated shade. Supports are painted black
- BAA (Buy American Act) and BABA (Build American, Buy America) compliant
MODELS:
CP2800-47
47" length
Spec Sheet Install IES RevitCP2800-63
63" length
Spec Sheet Install IES RevitCP2800-85
85" length
Spec Sheet Install IES Revit
Volare Linear Pendant Lights offer Non-VOC powder coat colors.
Painted
- Custom colors
- Custom lengths
Product Specifications & Documents
CP2800-47
47" length
- L
- W
- OAH
- WT
- 47-1/2” (1181 mm)
- 8-1/2” (216 mm)
- 120” (3048 mm)
- 5-1/2 lbs
- CCT
- 3000K
3500K
4000K
- Lumens
- L: 3000-3100
H: 4500-4700
- Watts
- L: 26
H: 41
- Driver
- Remote; Integral in canopy
- Control
- 0-10V to 1%
- Listings
- Damp
CP2800-63
63" length
- L
- W
- OAH
- WT
- 63” (1600 mm)
- 8-1/2” (216 mm)
- 120” (3048 mm)
- 7 lbs
- CCT
- 3000K
3500K
4000K
- Lumens
- L: 4000-4100
H: 6000-6200
- Watts
- L: 34
H: 53
- Driver
- Remote; Integral in canopy
- Control
- 0-10V to 1%
- Listings
- Damp
CP2800-85
85" length
- L
- W
- OAH
- WT
- 85” (2159 mm)
- 8-1/2” (216 mm)
- 120” (3048 mm)
- 9-1/2 lbs
- CCT
- 3000K
3500K
4000K
- Lumens
- L: 5400-5600
H: 8100-8500
- Watts
- L: 46
H: 72
- Driver
- Remote; Integral in canopy
- Control
- 0-10V to 1%
- Listings
- Damp
Product Video
VOLARE Linear Pendant
“The real wow factor of this light is the way the acrylic diffuser is illuminated. Without up-close inspection, it seems as though the thin upper diffuser is the illumination source” says product engineer Alex Murray. “The final design turned out to be somewhat of an artistic optical illusion, tricking the viewer as to how so much light could be emitted from seemingly nowhere. It’s one of my favorite fixtures I’ve ever been a part of producing.”
Linear Pendant Lighting With Remarkable Light Output
Optimized LED Performance
Volare stands out from other linear suspension lighting seen in the commercial pendant lighting market because of its beautiful glow, interesting curved shape, and its impressive light output. Most linear pendant lighting provides only downlighting which can create a cave-like atmosphere and harsh shadows. The improved performance of Volare provides usable surface downlight as well as uplight which then provides ambient illumination to the entire application space.
View the Volare Gallery
Linear Suspension Lighting With Style
An Advanced Commercial Pendant Light
Volare is available in 4’, 5’, and 7’ nominal lengths and is evenly lit with fully-dimmable LEDs and optional 90+ CRI for accurate color representation. These LED sources are available in L30K, L35K, and L40K LED color temperatures allowing this linear pendant to fit into a variety of commercial applications.
This pendant’s sleek design is credited to the pared down simplicity of elements used such as the cloth covered powered suspension cables eliminating a bulky power cord seen in similar fixtures. The LED light bar is suspended under the acrylic with hidden stand-offs and appears to float underneath the illuminated diffuser.
